PVC pipe extrusion line
1
2
3
4
6
7
PVC pipe extrusion line
1
2
3
4
6
7


PVC single pipe (1 in 1) extrusion line is made of a 51 or 65 or 80 conical twin screw extruder, one set of 1 in 1 mould, one set of calibration table , haul-off & cutter (dust free) and stacker.The diameter of the best production tube is from16mm to 63mm or 75mm to 160mm, 200-450mm.

Main features: high capacity, low power consumption, low water gas consumption, low occupation, low noise, low dust, etc.
Machine running video as follow


PVC  single pipe (1 in 1) extrusion line is made of a 51 or 65 or 80 conical twin screw extruder, one set of 1 in 1 mould, one set of calibration table , haul-off & cutter (dust free) and stacker.The diameter of the best production tube is from16mm to 63mm or 75mm to 160mm, 200-450mm.

Main features: high capacity, low power consumption, low water gas consumption, low occupation, low noise, low dust, etc.

type

pipe dia

extruder

max. output

max.line speed

machine length

PVC-1-63

16-63mm

CTS51

180kg/h

6m/min

20m

PVC-1-160

75-160mm

CTS65

250kg/h

5m/min

23m

PVC-1-400

200-400mm

CTS80

450kg/h

4m/min

25m

PVC-1-450

200-450mm

CTS92

650kg/h

2m/min

30m
